Key Features
-
DDR5 test coverage as described by JEDEC JESD79-5B
-
Test DDR5 up to 8400 MT/s
-
Measure DQ, DQS, CK, CA signals
-
Automated Compliance increases reliability
-
External MSO (HDA125) improves R/W packet separation accuracy
-
Save Pass/Fail PDF reports with annotated screenshots
-
Analyze compliance failures in a dedicated Debug Toolkit
QualiPHY 2
Automated DDR compliance testing enables faster test times by reducing inconsistencies, testing to the JEDEC standard and quick stopping for root-causing failures through the DDR Debug Toolkit.
-
Guides the user through each test setup
-
Performs each measurement in accordance with the relevant test procedure
-
Compares each measured value with the applicable specification limits
-
Fully documents all results in a saved PDF with measurement annotations
-
QualiPHY 2 helps the user perform testing the right way—every time!
